Over limit trip and peak detection Voltage ramp, key panel interlock, minimum current monitoring Remote-controllable (ASCII, Windows DLL, .NET Framework Assembly, DataView) Source-sense operation, test pistols with start automatic Monitoring of connection and cable failure 15 freely programmable sets of parameters Signalling: Acoustic, optical and via interface Safety circuit including two interlock safety relays

Test voltage	100 – 10,000 V AC, PI – regulated
Test current, limit	0.1 – 1000 mA
Power	> 500 VA
Short circ. current	> 200 mA, according to EN 61180
Testing time	1s – 99 min, endless
Potential free	Suitable for testing with test pistols, according to EN 50191
